Chrome bronze plate has the advantages of high stress relaxation resistance, good thermal stability, good electrical conductivity, good corrosion resistance, and good electroplating performance. The addition of chromium, on the one hand, obviously increases the recrystallization temperature and thermal strength of the alloy; on the other hand, the electrical conductivity of copper decreases slightly. The conductivity of solution treated chrome bronze rods is 45% IACS, which rises to 80% IACS after aging treatment. The softening temperature of aged chrome bronze is 400°C, which is twice that of cold-worked copper.


Chromium Bronze Strip1
Chromium Bronze Strip2


Chrome bronze has high strength and hardness at room temperature and below 400 ℃, good electrical and thermal conductivity, and good processing and forming performance. Make welding machine electrodes, motor commutators and other parts that work at high temperatures and require high strength, hardness, conductivity and conductivity. The working temperature is below 350°C, and can also be used in the form of bimetallic discs for brake discs and discs .

Chromium Bronze Strip3
Chromium Bronze Strip5
Chromium Bronze Strip4

Product Description

Item Zirconium Bronze Strip
Standard ASTM, AISI, JIS, ISO, EN, BS, GB, etc.
Material C18150、C18200、C18400、C18500
Size thickness: 0.1-200mm Width: 10-2000mm

Length: customized or on request

Size can be customized according to customer needs.

Surface Mill,polished,bright,oiled,hair line,brush,mirror,sand blast,

or as required.
